2- STROKE MARINE DIESEL ENGINE

A 2-stroke marine diesel engine is a type of internal combustion engine that completes all four stages of operation intake, compression, combustion, and exhaust in two piston strokes (one crankshaft revolution). It is primarily used in large ships such as tankers, container vessels, and bulk carriers because of its high power output, fuel efficiency, and ability to run continuously for long periods. The engine is designed to deliver maximum torque at low revolutions per minute (RPM), making it ideal for direct propulsion of heavy marine vessels.

Purpose

The main purpose of a 2-stroke marine diesel engine is to generate continuous propulsion power for ships during long-distance voyages. It provides high torque and efficiency at low speed, enabling vessels to move massive loads across oceans while minimizing fuel consumption. Its robust design, long service life, and ability to operate on different fuel types from heavy fuel oil (HFO) to marine diesel oil (MDO) make it the backbone of commercial marine propulsion.

Background and History

The concept of the 2-stroke engine emerged in the late 19th century, pioneered by Dugald Clerk (1878) and Joseph Day (1891). In the early 20th century, diesel technology replaced steam propulsion as shipping demanded greater efficiency. By the 1930s, manufacturers like Sulzer, MAN B&W, and Mitsubishi developed large-scale crosshead-type 2-stroke engines, setting the standard for ocean-going ships. Since the 1960s, these engines have dominated maritime transport, evolving to meet stricter emission and fuel efficiency standards.

Main Components and Functions

• Cylinder Liner : Forms the combustion chamber’s wall and withstands high pressure and temperature.
• Piston & Rings : Convert combustion energy to motion and maintain sealing between piston and liner.
• Connecting Rod & Crankshaft : Transfer and convert linear motion into rotary motion for propulsion.
• Crosshead Bearing : Separates the piston and connecting rod to prevent side forces.
• Scavenge Air System : Supplies fresh air for combustion and removes exhaust gases.
• Turbocharger : Utilizes exhaust gas energy to compress intake air for better combustion.
• Fuel Injector : Sprays atomized fuel into the combustion chamber for ignition.
• Exhaust Valve : Opens to release burnt gases.
• Cooling and Lubrication Systems : Control temperature and minimize wear.

ADVERTISMENT

Working Principle
The 2-stroke cycle has two main strokes:

Downward Stroke (Power and Exhaust): Fuel combusts, driving the piston downward. Exhaust gases exit as fresh air enters through scavenge ports.

Upward Stroke (Compression): The piston rises, compressing the air. Fuel is injected near the top dead center, igniting immediately to start a new cycle.
This means the engine produces one power stroke per revolution, providing greater power density than 4-stroke engines.

Advantages

•High power output at low RPM
•Excellent fuel efficiency for long voyages
•Strong, reliable, and durable design
•Simple direct coupling to the propeller shaft

Disadvantages

•Large and heavy machinery
•Complex scavenging system
•Higher vibration and noise levels
•Requires skilled maintenance and monitoring

Modern Developments

Modern 2-stroke engines feature electronic fuel injection, variable turbocharging, and automated control systems for enhanced efficiency. To meet IMO Tier III emission standards, technologies like Exhaust Gas Recirculation (EGR) and scrubbers are now widely used. Manufacturers such as MAN Energy Solutions and Wärtsilä are also developing dual-fuel engines that run on cleaner fuels like LNG, methanol, or ammonia, supporting global decarbonization goals.

Conclusion

The 2-stroke marine diesel engine remains the heart of global maritime propulsion, powering over 80% of the world’s commercial fleet. Its combination of efficiency, endurance, and adaptability ensures its continued importance as shipping transitions toward greener and more sustainable technologies.
