Parts of the Anchor System of a Ship
Sep 23, 2025



What is the Anchor System of a Ship?

The anchor system is essential equipment that secures a ship in place at sea or in port. It consists of interconnected parts such as the anchor, chain, windlass, and locker, working together to prevent drifting, protect the vessel, and ensure safety during operations, emergencies, or harsh weather conditions.

Parts of the Anchor System of a Ship

1. Anchor
A heavy steel device that grips the seabed to hold the ship in position. It prevents drifting due to wind, waves, or current, ensuring stability and safety.
2. Chain Cable
A strong, durable chain linking the anchor to the ship. Its weight and strength allow effective seabed penetration, withstand high tension, and resist corrosion in harsh marine conditions.
3. Windlass
A powerful mechanical device used to heave up or let go the anchor chain. Operated hydraulically, electrically, or manually, it ensures safe, efficient anchoring operations and controlled chain movement.
4. Chain Stopper
A securing device that locks the anchor chain when not in use. It relieves stress on the windlass, prevents chain slippage, and ensures safety during sailing or rough weather.
5. Anchor Lashing
Strong securing arrangement that holds the anchor firmly in place while the ship is underway. It prevents unwanted movement caused by vibration, waves, or ship motion, protecting vessel structures.
6. Hawse Pipe
A cylindrical pipe at the bow through which the anchor chain passes from deck to sea. It aligns and protects the chain, preventing friction damage and entanglement.

7. Stripper Bar
A guiding device located near the windlass. It clears the anchor chain from the gypsy, directing it smoothly into the spurling pipe, preventing jamming and ensuring efficient chain handling.
8. Spurling Pipe
Connects the windlass to the chain locker, guiding the anchor chain downward. It allows smooth transfer, prevents tangling, and withstands heavy chain impacts during retrieval and stowage operations.
9. Bitter End
The secured inboard end of the anchor chain, fixed inside the chain locker. It prevents accidental loss of the anchor and allows controlled release in emergencies for safety.
10. Chain Locker
A compartment below deck where the anchor chain is stored. It keeps the chain organized, ventilated, and corrosion-free, while containing movement and ensuring readiness for anchoring operations.


Importance of the Anchor System

The anchor system ensures ship stability, prevents drifting, and enhances safety during loading, unloading, or rough seas. It protects the vessel, crew, and cargo while ensuring smooth, reliable, and efficient maritime operations.
