IMMERSION SUIT: Essential Survival Gear for Every Seafarer

An immersion suit also called a survival suit is a life-saving garment designed to keep seafarers protected in the event of abandoning ship, especially in cold waters. Made of insulated, waterproof material, it drastically slows body heat loss and increases chances of rescue. Purpose • Thermal Protection: Retains body heat to prevent hypothermia. • Buoyancy: Keeps the wearer afloat without the need to swim. • Visibility: High-visibility color and reflective tape help rescuers locate survivors quickly. • Survivability: Protects against wind, waves, and freezing temperatures while awaiting rescue.

PARTS OF A SHIP

Front (Bow) Area Bulbous Bow A rounded projection located below the waterline at the forward part of the hull. It reduces wave resistance and helps improve the ship’s fuel efficiency and stability. Bow The forward-most section of the ship designed to cut through the water as the vessel moves. Stem The vertical front edge of the bow that forms the main support where the two sides of the hull meet. Foredeck The deck area located at the forward part of the ship, often used for anchor handling and mooring operations. Fore Mast A mast positioned near the bow used to mount lights, radar, antennas, and other navigational instruments. Hatch Cover A watertight cover placed over cargo holds to protect the cargo from seawater and weather exposure. Deck The main working platform of the ship where crew activities and operations take place. Hull The main outer structure or body of the ship that provides buoyancy and keeps the vessel afloat. Anchor A heavy device lowered to the seabed to hold the ship in position and prevent drifting. Bridge The command center of the ship where navigation, control, and monitoring of vessel movement and operations are performed. Midship and Superstructure Superstructure The portion of the ship constructed above the main deck, housing key operational and living spaces. Accommodation The area where the crew lives and works. It includes cabins, mess rooms, offices, and other essential living facilities. Flying Bridge / Bridge Wings Side platforms extending from the bridge used for maneuvering and observation, especially during docking and unmooring. Monkey Island An open platform located above the bridge that provides access to radar, communication, and navigation equipment, as well as offering an unobstructed view of the surroundings. Main Mast The primary mast supporting communication systems, navigation lights, and other electronic devices.

Fire Extinguisher

A fire extinguisher is a portable safety device designed to control or put out small fires in emergency situations. It works by releasing a fire-suppressing agent that cools the fire, removes oxygen, or interrupts the chemical reaction of combustion. Fire extinguishers are commonly found on ships, buildings, and industrial areas as part of basic fire-fighting equipment. Main Parts and Their Functions Discharge Lever – When squeezed, it releases the extinguishing agent. Safety Pin – Prevents accidental discharge; must be pulled before use. Carrying Handle – Allows safe handling and control during operation. Pressure Gauge – Indicates whether the extinguisher is properly pressurized and ready for use. Pickup Tube (Siphon Tube) – Draws the extinguishing agent from the bottom of the cylinder. Gas Canister – Contains compressed gas that pushes the extinguishing agent out. Extinguishing Agent – The substance used to fight the fire (e.g., dry powder, foam, CO₂). Discharge Nozzle / Hose – Directs the agent accurately toward the base of the fire. Fire extinguishers are vital first-response tools and must always be properly maintained and correctly used for effective fire control.

Central Cooling System

Central Cooling System (CCS) on Ships The Central Cooling System (CCS) is the primary method used on modern vessels to maintain safe operating temperatures for engines and auxiliary machinery. Instead of relying on multiple separate cooling circuits, a CCS uses a single freshwater loop to cool major equipment. This freshwater absorbs heat from engines and machinery and then transfers that heat to seawater through a central cooler. By using freshwater internally and seawater externally, the system offers both efficiency and protection for vital components. Purpose of the Central Cooling System The CCS is designed to provide a stable and controlled cooling environment for the ship’s mechanical systems. Its main purposes include: •Preventing Overheating: Engines, compressors, generators, and pumps produce significant heat during operation. The CCS ensures they remain within safe temperature ranges. •Reducing Corrosion: Freshwater circulates inside machinery rather than corrosive seawater, greatly extending equipment lifespan. •Improving Efficiency: Consistent cooling improves fuel efficiency, power output, and overall engine performance •Simplifying Maintenance: A centralized system requires fewer individual coolers, making inspection and repairs easier and more cost-effective. •Environmental and Safety Protection: Proper cooling prevents machinery failures that could lead to pollution, downtime, or emergency situations. A Brief History of Marine Cooling Systems Early ships relied on direct seawater cooling, where seawater passed directly through engines. While simple, this system caused rapid corrosion, fouling, and frequent breakdowns. As engine outputs increased with advancements in marine propulsion, a more reliable and controlled method became necessary. By the mid- 20th century, ships shifted toward a jacket-water (freshwater) cooling system, where freshwater circulated around the engine block. However, many small coolers were still used for individual machinery, creating complexity. The modern Central Cooling System emerged as a solution: •One freshwater loop for all machinery •One central cooler to transfer heat to seawater •Better temperature control and lower maintenance Today, the CCS is standard on most commercial vessels due to its efficiency and durability.
